The following ADS simulation will demonstrate how the characteristic impedance and effective dielectric constant change with frequency. In the simulation, a quarter wave section of multi-layer microstrip line is used to demonstrate frequency effects. The result are expected to show that the dielectric constant and the characteristic impedance are inversely related. When the frequency of the electric field increases, the permittivity decreases because the electric dipoles cannot react as quickly. The multi-layer component is used in place of an ideal component because frequency dependence must be demonstrated. An “MLSUBSTRATE2” component is used with the updated dielectric constant and Dielectric loss tangent.

For S parameter analysis, two terminated grounds are required. The effective dielectric constant must be solved for by unwrapping the phase of S(2,1). The results show the characteristic impedance (both real and imaginary parts) increasing with frequency and the dielectric constant decreasing.
